| Image Sensor |
1/2.8” 2MP PS CMOS Image Sensor (0.9071 centimeter) |
| Min. Illumination |
Colour Mode 0.0021 Lux @F1.6, Night Mode (B&W) 0.00021Lux @F1.6 |
| Effective Pixels |
1920 (H) × 1080 (V) |
| Shutter Speed |
Auto/Manual, 1/3 s–1/100000 s |
| RAM / ROM |
512 MB / 512 MB |
| Lens Support |
C/CS Mount |
| Image Settings |
White Balance, AGC (Auto), BLC / HLC / WDR (120dB), 3D DNR, EIS, Defog |
| Video Compression |
Instastream, H.265, H.264+, H.264, H.264B, H.264H, MJPEG (sub stream only) |
| Resolution |
2MP(1920×1080), 1.3M(1280×960), 1MP(1280×720), D1, VGA, CIF |
| Frame Rate |
Main stream: 1-25/30fps
Sub stream 1/2/3: 1-25/30fps |
| Bit Rate |
CBR/VBR | H.264/H.265: 3 kbps–6144 kbps |
| Motion & AI |
Motion Detection (8 Areas), Tripwire, Intrusion, Object Abandon/Missing, SMD, Face Detection |
| Audio |
1 Ch Input, Two-way Talk Support
Compression: PCM, G.711a, G.711Mu, G.726, MPEG2-Layer2, G.722 |
| Alarm Interface |
IN: 2 channels (3–5 VDC)
OUT: 2 channels (1,000 mA 30 VDC / 500 mA 50 VAC) |
| Network & Protocols |
IPv4, IPv6, HTTP, HTTPS, RTSPS, SMTP, SFTP, DHCP, ONVIF (Profile S, G, T), and more. |
| Storage |
SFTP, NAS, Micro SD card (max. 512 GB) |
| Certificates |
MTBF (STQC), EMI/EMC, ISO9001, CE, FCC, RoHS, BIS, STQC |
| Power |
Source: DC 12V / AC 24V / PoE
Consumption: <10W
Output: 12 VDC (Max 165mA) |
| Environment & Physical |
Temp: -30°C to +60°C
Dims: 161.6mm × 86.8mm × 74.0mm
Weight: 0.8kg |
