2MP Network IR Wedge Camera - 30Mtr.
CP-UNC-WE21L3C-MDS-Q
| Image Sensor | 1/2.8” 2MP PS CMOS (0.9071 centimeter) |
| Min. Illumination | 0.006 Lux@F1.6 (Color) | 0.0006 Lux@F1.6 (B/W) | 0 Lux (IR On) |
| Lens Specifications |
Type: 2.8mm Fixed (3.6mm optional) | Mount: M12 Aperture: Fixed Iris |
| Angle of View (2.8mm) | Horizontal: 107° | Vertical: 56.3° | Diagonal: 126.4° |
| Angle Adjustment | Pan: -30°~30° | Tilt: 0°~80° | Rotation: 0°~360° |
| Video Compression | Instastream, H.265, H.264+, H.264, H.264H, H.264B, MJPEG (Sub stream) |
| Frame Rate |
Main: 2MP/1.3MP/1MP/D1 @ 1-25/30fps Sub Streams: D1/VGA/CIF/2MP @ 1-25/30fps (Triple Stream Support) |
| Image Enhancement | WDR(120 dB), BLC, HLC, 3D DNR, Privacy Mask (8 Areas), White Balance (Auto/Manual), S/N > 54dB |
| Audio Compression | PCM, G.711a, G.711Mu, G.726, MPEG2-Layer2, G.722.1 |
| IVS (AI Features) | Tripwire, Intrusion, Object Abandon/Missing, SMD, Face Detection |
| Alarm Events | Motion, Tampering, Audio Detection, Network Disconnect, IP Conflict, Memory Errors |
| Cyber Security | AES 256-bit Encryption, Trusted Boot/Upgrade/Execution, Configuration Encryption, IP/MAC Filtering, WSSE, Account Lockout, Syslog |
| Connectivity |
Ethernet: 1x Built-in M12 Port (10/100M) Protocols: IPv4/v6, HTTPS, RTSP, SFTP, ONVIF (S/G/T), etc. |
| Storage | Micro SD Card (Max. 512 GB), NAS, SFTP |
| Night Vision | IR Range: 30 Meters (2 IR Lights) | Day/Night (ICR) |
| Power |
Source: PoE (802.3af) Consumption: < 4.5 W |
| Environment |
Temp: –40°C to +70°C (85°C for 10 min) Protection: IP67 (Weatherproof), IK10 (Vandal Proof) |
| Physical | Casing: Metal | Dims: 64.8mm × 111.0mm | Weight: 0.45kg |
