| Image Sensor |
1/2.8” 2MP PS CMOS (0.9071 cm) |
| Min. Illumination |
0.006 Lux@F1.6 (Color, 30IRE)
0.0006 Lux@F1.6 (B/W, 30IRE)
0 Lux (IR on) |
| Lens Specs |
Type: 2.7mm ~ 13.5mm Motorized (F1.5)
Mount: M14 | Angle: H: 109°–30°, V: 56°–17°
|
| DORI Distance |
Wide: Det: 44m, Obs: 17m, Rec: 8m, Id: 4m
Tele: Det: 144m, Obs: 57m, Rec: 29m, Id: 14m
|
| Pan / Tilt / Rotate |
Pan: 0°–355° | Tilt: 0°–65° | Rotation: 0°–355° |
| Video Compression |
Instastream, H.265, H.264+, H.264, H.264H, H.264B, MJPEG (Sub stream) |
| Resolution |
2MP (1920×1080), 1.3MP, 1MP, D1, VGA, CIF |
| Frame Rate |
Main: 2MP/1.3MP/1MP/D1 @ 25/30fps
Sub 1/2/3: Support up to 25/30fps (D1/VGA/CIF/2MP mix)
|
| Image Enhancement |
WDR(120dB), BLC, HLC, 3D DNR, EIS (Stabilization), Defog, ROI (4 Areas), Privacy Mask (4 Areas) |
| Audio |
Built-in Mic | 1 Ch Output (RCA)
Compression: G.711a, G.711Mu, G.726, AAC, etc. |
| Alarm Interface |
1 In (5mA 3V–5V DC) | 1 Out (300mA 12V DC) |
| IVS & AI |
Tripwire, Intrusion, Object Abandon/Missing, SMD, Face Detection |
| Network Protocols |
IPv4, IPv6, HTTP, HTTPS, RTSPS, ONVIF (Profile S/G/T), SMTP, SFTP, DHCP, NTP, Multicast, etc. |
| Storage |
Micro SD Card (Max 512 GB), NAS, SFTP |
| Power |
Source: 12 VDC / 24 VAC / PoE (802.3af)
Consumption: Basic: ~3W | Max (IR+AI+WDR): ~9.9W
|
| Environment |
Rating: IP67 (Weatherproof)
Temp: -30°C to +60°C
|
| Dimensions & Weight |
159.1 mm × 118.1 mm | 0.91 kg |
