| Image Sensor |
1/2.8” 2MP PS CMOS (0.9071 centimeter) |
| Min. Illumination |
0.006 Lux@F1.6 (Color, 30IRE) | 0.006 Lux@F1.6 (B/W, 30IRE) | 0 Lux (IR on) |
| Lens Specifications |
Focal Length: 2.7 mm–13.5 mm (Motorized Vari-focal)
Aperture: F1.6 (Fixed Iris) | Mount: M14
Close Focus: 0.8 Mtr.
|
| Angle of View |
Horizontal: 109°–30° | Vertical: 56°–17° | Diagonal: 131°–35° |
| DORI Distance |
Wide: Det: 44.1m, Obs: 17.7m, Rec: 8.8m, Id: 4.4m
Tele: Det: 144.8m, Obs: 57.9m, Rec: 29.0m, Id: 14.5m
|
| Pan / Tilt / Rotation |
Pan: 0°–360° | Tilt: 0°–90° | Rotation: 0°–360° |
| Video Compression |
Instastream, H.265, H.264+, H.264, H.264H, H.264B, MJPEG (Sub stream) |
| Resolution |
2MP (1920×1080), 1.3M, 1MP, D1, VGA, CIF |
| Frame Rate |
Main: 2MP/1.3MP/1MP/D1 @ 25/30fps
Sub Streams: Support D1/VGA/CIF/2MP @ 25/30fps (Quad Stream)
|
| Image Enhancement |
WDR(120dB), BLC, HLC, 2D DNR, EIS (Stabilization), Defog, ROI, White Balance (Auto/Natural/Street/Outdoor) |
| Audio Interface |
1 In / 1 Out (RCA Ports)
Compression: G.711a, G.711Mu, G.726, MPEG2-Layer2, G.722.1 |
| Alarm & Events |
Input: 1 Channel (5mA 3V–5V DC)
Events: Motion, Tampering, Audio Detection, Network Disconnect, IP Conflict, Storage Errors
|
| IVS (Intelligent Video) |
Tripwire, Intrusion, Object Abandon/Missing, SMD, Face Detection |
| Network Protocols |
IPv4/IPv6, HTTP/HTTPS, RTSPS, ONVIF (Profile S/G/T), SFTP, SMTP, DHCP, NTP, Multicast, etc. |
| Storage |
Micro SD Card (Max. 512GB), NAS, FTP |
| Night Vision |
IR Range: 60 Meters (4 IR LEDs) | Day/Night (ICR) |
| Power |
Source: 12 VDC / PoE (802.3af)
Consumption: Basic: 1.6W (12V) / 3.3W (PoE) | Max: 9.6W (12V) / 11.9W (PoE)
|
| Environment |
Operating Temp: –30°C to +60°C | Humidity: ≤95% RH |
| Dimensions & Weight |
273.2 mm × 95.0 mm × 95.0 mm | 1.10 kg |
